| Product Attribute | Attribute Value |
|---|---|
| Application | For medical equipment, office equipment and test equipment |
| Approvals | CE Compliant, UL Recognized |
| Connection Type | Screw |
| Cut Out, Panel | 1.81 sq.in., 1.99" Dia. |
| Depth | 0.157" (4mm) |
| Dimensions | 1.6" H x 2.93" Dia. |
| Dimensions, Cutout, Inches | 50 (Dia.) mm |
| Display Digit Height | 3.6 mm |
| Display Type | Digital |
| Frequency, Operating | 60 Hz |
| Function | Hour Meter |
| Input Type | Voltage |
| Measurement Range | 0 to 99999.99 hrs. |
| Measuring Range | 0 to 99999.99 hrs. |
| Minimum Operating Temperature | -10 °C |
| Mounting Type | Panel |
| Number of Digits | 7 Digits |
| Operating Temperature | -30 to 70 °C |
| Power Rating | 3 (AC)/1.2 (DC) W |
| Primary Type | Electromechanical |
| Product Header | Electromechanical Hour Meter |
| Series | |
| Standards | UL Recognized, CE Approved and CSA Certified |
| Supply Voltage | 115 VAC VAC |
| Temperature Range | -10 to 60 °C |
| Temperature, Opening, Maximum | 60 °C |
| Termination | Screw |
| Type | Electromechanical |
| Voltage Rating | 115 VAC |
Overview
Electromechanical 7-digit AC Hour Meter with 0.14" high figures. Records up to 99,999.99 hours. Available in square bezel mount with retainer clip. UL Recognized, CE Compliant and CSA Certified. Panel cutout: 1.81" square.
